Esp8266 Rc522

Tested ESP8266 with RC522 NFC/RFID Reader

RC522 is NFC/RFID reader, and it can be integrated into ESPHOME

  • esphome configuration

    # Example configuration entry
    http_request:

    output:
    - platform: esp8266_pwm
      pin: 5
      id: my_buzzer

    rtttl:
      output: my_buzzer
      gain: 0.1

    spi:
      clk_pin: 14
      mosi_pin: 13
      miso_pin: 12

    rc522_spi:
      cs_pin: 15
      on_tag:
        then:
          - http_request.send:
              method: POST
              url: !secret nfc_tag_call_url
              verify_ssl: false
              headers:
                Content-Type: application/json
              json:
                tag: !lambda
                  return x;
          - rtttl.play:
              # rtttl: 'siren:d=8,o=5,b=100:d,e,d,e,d,e,d,e'
              rtttl: 'two_short:d=4,o=5,b=100:16e6,16e6'

    binary_sensor:
      - platform: rc522
        uid: !secret my_room_card
        name: "My Room Card"

  • Two separate function

    • binary_sensor is used by Home Assistant (see below)
    • rc522_spi.on_tag : when nfc card is tagged, we call two services
      • http_request.send : send to the server for additional automation
      • rtttl.play : will play buzzer sound for user to recognize the touch has been read

Home automation

  • Security on
    alias: my-room-card-tagged-securityon
    description: ""
    trigger:
      - platform: state
        entity_id:
          - binary_sensor.my_room_card
        from: "off"
        to: "on"
    condition:
      - condition: state
        entity_id: automation.body_detected
        state: "off"
    action:
      - service: automation.turn_on
        target:
          entity_id:
            - automation.body_detected
        data: {}
      - service: tts.google_translate_say
        data:
          cache: false
          entity_id: media_player.living_room_speaker
          message: Turned on security
    mode: single

  • Security off
    alias: my-room-card-tagged-securityoff
    description: ""
    trigger:
      - platform: state
        entity_id:
          - binary_sensor.my_room_card
        from: "off"
        to: "on"
    condition:
      - condition: state
        entity_id: automation.body_detected
        state: "on"
    action:
      - service: automation.turn_off
        target:
          entity_id:
            - automation.body_detected
        data:
          stop_actions: true
      - service: tts.google_translate_say
        data:
          cache: false
          entity_id: media_player.living_room_speaker
          message: Turned off security
    mode: single


Look

D1 Mini Pro and RC522 Sensor D1 Mini Pro and RC522 Sensor
